The KA Series 0.037″ thick RF absorber material is an iron-loaded silicone elastomer optimized for the Ka band (27.0 to 40.0 GHz). It is the thinnest elastomer absorber in the 3PB Solutions product line, designed for superior cavity resonance reduction at the highest mmWave frequencies in the sheet absorber range.

The KA Series targets 5G FR2 applications including the n257 band (26.50 to 29.50 GHz), n260 band (37.00 to 40.00 GHz), and n261 band (27.50 to 28.35 GHz), as well as Ka-band satellite communications and precision mmWave test equipment. For lower frequencies, see the KB Series (18.0 to 27.0 GHz). For applications requiring a non-silicone alternative, consider the US Series acrylic elastomer.

Key Specifications
Base material: Iron-loaded silicone
Thickness: 0.037″ (0.940 mm)
Frequency range: 27.0 to 40.0 GHz (Ka Band)
Operating temperature: -55 to 200°C
Density: 2.930 g/cm³
Adhesive: PSA backing available (3M 9485PC)
Compliance: RoHS/REACH compliant, halogen-free

Common Applications
Cavity resonance suppression in compact mmWave enclosures, near-field noise suppression, surface current reduction, and EMC compliance in 5G FR2 antenna modules, Ka-band satellite transponders, mmWave point-to-point links, automotive radar sensor housings, and precision mmWave test and measurement equipment.

Need a custom die-cut shape, a thickness not listed here, or a large production quantity? Contact our engineering team for a quote. Custom die-cut parts with PSA backing ship in 2 to 3 weeks.

For complex permeability and permittivity data for electromagnetic simulation (HFSS, CST, COMSOL), email us or give us a call at 855-785-5660.
